Quick Overview

Heavy duty mini HD camera substr/top mounting camera; 960*480 (NTSC)
119,00€

αγόρασε το και με :

Χαρακτηριστικά:

Χρόνος αποστολής: 1-2 Ημέρες

Περιγραφή

New Page 1
Heavy duty mini HD camera substr/top mounting camera; 960*480; IP69K (NTSC)


Features
- 1/4? SONY CMOS HD Color Sensor
- Vibration & impact resistant housing
- IP69K Waterproof rating
- 160 degrees lens
- WDR (Wide Dynamic Range)
- High End Night View (0.02Lux) without LEDs
- Anti-glare & ghost
- Voltage range (10V-24V)
- Extreme Temp. Durability
Operating: -30°C ~ 70°C
Storing Temp. : -40°C ~ 80°C
- 4-pins Mini connector to RCA
- Parking guide lines wire (ON / OFF)
- Substructure (vertical) & top (horizontal) mounting wire
- CE-mark
- FCC-mark
- 2 Year warranty & Support


EXCLUSIVE CAMERA FEATURES


SONY CCD

High End 1/4? SONY CMOS HD Color Sensor with 960*480 resolution



Parking Guide line
Parking guide line ON/OFF wire

Horizontal/Vertical mounting
Horizontal or vertical mounting wire

Igntion Power proof (+15)
It is possible to connect the powersupply to an ignition feed (+15), because we use the highest quality camera.
In this way you are able to watch the camera also in DRIVE gear or via manual selection.



NOTES
- We recommend that the installation will be performed by a qualified specialist
- Check also the other tabs for "Compatibility" - "Package contents" - "Product specifications"


LEGAL NOTICE
Please check before purchase if it is aloud to install this camera and it wont affect your MOT.

Compatibility

Loading…..

Specifications

Voltage supply: 12V
Operation voltage: 10V - 24V
Sensor: 1/4 SONY CMOS HD
Resolution:  960x480 pixels
TV line: 650-700 TVL
Video output: 1Vp-p,75Ohm
Lens: 160 ° (Degrees)
Connection: 4-pins mini to RCA output
Image: Mirror
TV system: NTSC
IR led: No
Night vision: Excellen Nigh view (0.02 Lux) without LED's
Operating Temperature: -30°C to +70°C
Storing Temperature: -40°C to +80°C
Back Light Compensation: Automatic
Microphone: No
Waterproof: IP69K
WDR (Wide Dynamic Range): Yes
Vibration & impact reistant: Yes
Sizes: 28mm x 30mm (camera only)
FFC: Yes
CE: Yes

Παρατηρήσεις

New Page 2
Universal use
Only for rear installation



NOTES

- RCA output = male
- CVBS signal is NTSC

Περιλαμβάνει

Package:
  1. HD camera with extend wire 2 meter 1x
  2. Power & extend cable 5 meter: 1x
  3. Mounting tools: 1x
  4. Installation instructions: 1x
