SPECIFICATIONSDimensions
Camera: 23.6x 23.6x 24.0mm (excluding projection on the rear)
Camera Cable Length: 0.5m
Camera Extension Cable Length: 10.5m
General
Power Requirement: 6.0 V.DC
Negative Ground
Max. Power Consumption: 0.5W
Weight Camera: 27g (including cable)
Camera
Output Image: Mirror Image, Composite Video (NTSC Color Signal System)
Image Output: 1 Vp-p (75 Ohms)
Image Sensor: 1/3.7 inch CMOS Image Sensor, Aspect Ratio 4:3
Effective Number of Pixels: 640 (H) x 480 (V), Approximately 0.3 Mega pixels
Lens Focal Length: f=1.34mm
Lens Brightness: F=1:2.0
Angle of Field: Horizontal = 131°, Vertical = 103°
S/N Ratio: 40.5 dB or more
Resolution (Horizontal. Center Area): 330 TV Lines
Operating Temperature: -30°C - +70°C
Illumination Range: Approximately 1.5 to 100klx
