Technical data
- Contact rating: incandescent lamps (230V) 800W
- Compensated fluorescent lamps (230 V) 360 W
- Control duration: Max 1 h
Type | 26.01.8.012.0000 |
---|---|
Operating voltage | 12 Vac |
Switching capacity | Max(AC1) 2500 VA/(AC15, 230 V) 500 VA |
Switching voltage | Max 400 V/AC / 220 Vdc |
Switching current | 10 A |
Protection type | IP20 |
Contact material | AgNi |
Max. permanent current | (AC1) 10 A/250(V/AC) 450 |
Contact type | SPST-NO |
Switch-on current | Max 20 A |
Step 2 | ON |
Switching sequence step 1 | OFF |
